The VetOvation Seal + Cut is a 4-in-1 electrosurgery system. It is an advanced energy platform that includes autoclavable accessories. A Smoke Evacuator is also included for the safety of your patients and your staff. The Seal + Cut system includes all the following components:
- 200-watt Vetergy Electrosurgery Unit
- Smoke Evacuator
- Reusable + Autoclavable Bipolar Vessel Sealing Clamp + Cable
- Reusable + Autoclavable Bipolar Forceps + Cable
- Reusable + Autoclavable Monopolar Pencil/Cable
- Reusable grounding plate/cable
- Set of 10 electrode tips
- Foot pedal
- Disposable Monopolar Pencils (4)
- Smoke Evacuation Tubing
- Smoke Evacuation Tubing with Monopolar Pencil Handle
VETERGY 200 is a digital radio frequency 200 watt electrosurgical generator which is suitable for veterinary surgery. Cautery is hand-controlled or by the use of a foot pedal. The generator that performs precision monopolar and bipolar surgery in addition to microsurgery. It is designed for ease of use utilizing a 7″ touch screen with an intuitive interface. Pre-programmed surgery protocols helps streamline setup and regulate power usage. This electrosurgery unit offers the ability for hand or foot control.
FEATURES
Max output power CUT 200 W-300 Ω
Max output power BLEND 150 W-300 Ω
Max output power ENHANCED 150 W-300 Ω
Max output power FORCED COAG 150 W-800 Ω
Max output power SOFT COAG 100 W-200 Ω
Max output power SPRAY COAG 100 W-1000 Ω
Max output power BIPOLAR CUT 100 W-50 Ω
Max output power BIPOLAR COAG 100 W-50 Ω
Max output power VESSEL SEALING 200 W-25 Ω
Working frequency 360 kHz
RF power pulse emission time 10 ms – 30 sec
RF power pulse interval 1 – 30
Patient circuit F
Selectable input voltage 115 – 230 Vac
Mains frequency 50 – 60 Hz
Electrical input power 500 VA
VetOvation SURTRON Smoke Evacuator works in conjunction with the VETERGY 200 and the other Surtron electrosurgery generators and is suitable for veterinary surgery. Activation of the aspiration can be: AUTOMATIC, through electronic system of survey of the activation of the high frequency electrosurgical unit; MANUAL, acting directly on the unit through a foot switch (optional). The flux of the aspiration can be regulated to be suitable with the singular necessities. For laparoscopic procedures there is a specific function, quickly selectable.
FEATURES
Input voltage 230 Vac or 115 Vac
Mains frequency 50 Hz
Electrical input power 800 VA
Max vacuum flow rate 1000 LPM (35 CFM)
Max static suction 250 mbar (83 in H2O)
Filter type ULPA with active carbon
Filter efficiency 99,999X%
Particles diameter 0,12 micron
Max vacuum flow rate with filter 300 LPM (11 CFM)
Size WxHxD 370x144x319 mm
Weight 4 Kg
