Veterinary Video Otoscope System

Adaptor attaches to an iPhone.

The video otoscope adaptor is available for iPhone 6/6S, 6+/6S+, 7/7s, 7+/7s+, 8/8s, 8+/8s+, X/XS, XR, XS Max, SE, 11, 11 Pro, 11 Pro Max, 12/12 Pro, 12 Pro Max, 13/13 Pro and 13 Pro Max, 14/14 Pro, 14 Pro Max, and 15, 15 Pro, 15 Pro Max, 16, 16 Plus, 16 Pro and 16 Pro Max. Please indicate which device version you will be using with the system.

The system comes with everything you need to perform video otoscopy. Our veterinary video otoscope adapter, or smartScope, connects to an iPhone, using its camera technology to provide a high-definition image of the anatomy that can be shared with the client during the exam or via email. This allows your practice to utilize quality imaging to pinpoint recurrent or underlying problems inside the ear. The dual channel makes flushing and removing foreign objects such as foxtails quick and easy. The video system is also helpful during difficult intubation of small and large animals.

Components included with the video otoscope system:
• Endoscope adaptor that attaches scope to any compatible iPhone
• Scope – 0 degree 6.0mm X 90mm dual channel sheath accepts flexible grasper and continuous lavage.
• Flexible serrated grasper/biopsy instrument 5Fr x 260mm
• 320 Lumen LED light with rechargeable lithium battery and charging station
• Storage case for the smartScope components

The endoscope adaptor connects to any standard rigid or flexible scope so that images from the scope can be seen on the device screen.

Procedure Overview of the Video Otoscope iPhone Adapter System

This easy-to-use device enables:
Diagnostic evaluations
This is a simple yet technologically superior method to perform diagnostic procedures in the mouth and ears. When you see more you can treat more.

Therapeutic Treatments
• Video Otoscopy – The system allows for quick and easy inspection of the middle ear, removal of excessive hair and wax, along with examination of the tympanic membrane; this is an invaluable tool for animals with recurrent ear infections.
• Rhinoscopy – Utilizing a 6.0mm zero-degree scope with a working channel enables biopsy, flushing, and removal of foreign objects in the nasal cavity.
• Intubation – Easier method to intubate rabbits and other animals.

Client Education
The VetOvation smartScope allows sharing of videos and images with clients during the visit as well as through email communication.
